gdh high precision low tempera
professional manufacturer of laboratory equipment

low temperature thermostatic bath is widely used in petroleum chemical industry, electronic instruments, physics, chemistry, bioengineering, medicine and health, life science, light industry, food physical property testing and chemical analysis and other research departments, colleges and universities, enterprise quality inspection and production departments provide users with a cold and hot controlled field source with uniform and constant temperature when working, and conduct constant temperature experiments or tests on experimental samples or produced products.

product introduction
related videos
product details
unique advantages
parameter comparison
factory appearance
honor and qualification
common problem

see the true chapter for details

tianling's advantages are obvious to all

unique product features:

the high-precision low-temperature constant temperature bath is suitable for various research, application technology, production, quality inspection and other laboratory and industrial fields, and provides an accurate constant temperature system in the full range of temperature.

● large screen lcd with digital display resolution of 0.001 ℃

● adopt high-efficiency air-cooled totally enclosed compressor unit for refrigeration, with fast cooling speed and low noise. the refrigeration system has multiple automatic protection devices such as overheating and overcurrent.

● the deviation of temperature measurement value can be corrected, and the temperature display accuracy can reach 0.001 ℃

● it adopts high-precision software, which is easy to operate, has strong temperature stability, and can be adjusted automatically or manually by pid.

● upper and lower temperature alarms can be set.

● it can be equipped with circulating pump to establish the second constant temperature field outside the machine or the second laboratory container outside the cooler.

● it can be equipped with rs232 or rs485 communication interface to realize data transmission and remote control.

technical parameter

model	temperature（℃）	resolving power（℃）	volatility（±℃）	volume（l）	slot opening（mm）	groove depth（mm）	circulation mode	power（kw）	overall dimension（mm）	market price (yuan)
gdh-0506	-5~100	0.001	0.005-0.02	6	180*160	150	internal circulation	0.8	320370675	11300
gdh-1006	-10~100	0.001	0.005-0.02	6	180*160	150	internal circulation	0.9	320370675	11700
gdh-2006	-20~100	0.001	0.005-0.02	6	180*160	150	internal circulation	1.0	320370675	12300
gdh-3006	-30~100	0.001	0.005-0.02	6	180*160	150	internal circulation	1.5	320370765	14200
gdh-4006	-40~100	0.001	0.005-0.02	6	180*160	150	internal circulation	2.1	400450940	24900
gdh-0510	-5~100	0.001	0.005-0.02	10	180*160	200	internal circulation	1.3	320370765	12000
gdh-1010	-10~100	0.001	0.005-0.02	10	180*160	200	internal circulation	1.5	320370765	12900
gdh-2010	-20~100	0.001	0.005-0.02	10	180*160	200	internal circulation	1.8	320370765	14100
gdh-3010	-30~100	0.001	0.005-0.02	10	180*160	200	internal circulation	2.0	320370765	16200
gdh-4010	-40~100	0.001	0.005-0.02	10	180*160	200	internal circulation	2.1	400450940	29500
gdh-0515	-5~100	0.001	0.005-0.02	15	250*160	200	internal circulation	2.1	320370765	14500
gdh-1015	-10~100	0.001	0.005-0.02	15	250*160	200	internal circulation	2.2	320370765	15200
gdh-2015	-20~100	0.001	0.005-0.02	15	250*160	200	internal circulation	2.3	320370765	16200
gdh-3015	-30~100	0.001	0.005-0.02	15	250*160	200	internal circulation	2.4	320370765	21000
gdh-4015	-40~100	0.001	0.005-0.02	15	250*160	200	internal circulation	2.5	450540990	32000
gdh-0520	-5~100	0.001	0.005-0.02	20	250*160	300	internal circulation	2.3	4004501040	18000
gdh-1020	-10~100	0.001	0.005-0.02	20	250*160	300	internal circulation	2.4	4004501040	19200
gdh-2020	-20~100	0.001	0.005-0.02	20	250*160	300	internal circulation	2.5	4004501040	21300
gdh-3020	-30~100	0.001	0.005-0.02	20	250*160	300	internal circulation	2.6	4004501040	30500
gdh-4020	-40~100	0.001	0.005-0.02	20	250*160	300	internal circulation	2.7	4505401090	33500
gdh-0530	-5~100	0.001	0.005-0.02	30	330*280	230	internal circulation	2.5	450540990	20900
gdh-1030	-10~100	0.001	0.005-0.02	30	330*280	230	internal circulation	2.6	450540990	22900
gdh-2030	-20~100	0.001	0.005-0.02	30	330*280	230	internal circulation	2.7	450540990	26500
gdh-3030	-30~100	0.001	0.005-0.02	30	330*280	230	internal circulation	2.7	450540990	33200
gdh-4030	-40~100	0.001	0.005-0.02	30	330*280	230	internal circulation	3.0	4505401090	40800
